Q-G WALL PLATE RECEPTACLES
PHONE: 773 792-2700
26
CONNECTORS & RECEPTACLES
?
* Please visit the product pages on our website for the most up-to-date product information
Q-G ? WALL PLATE RECEPTACLES
G(*)M WALL PLATE RECEPTACLE
Wall plate with one B3M or B4M male
receptacle mounted (in “D”-shaped
hole to prevent turning) on standard
single electrical outlet box. Cover
mounting screws included.
J(*)F WALL PLATE RECEPTACLE
Wall plate with one, D3F or D4F female
receptacle. Mounts on standard single
electrical outlet box. Cover mounting
screws included.
Part
Insert
Part
Insert
Number
? G3MS
? G4MS
Finish
Stainless
Steel
Pins
3
4
Number
? J3FS
? J4MS
Finish
Stainless
Steel
Pins
3
4
? Special order only. Contact Switchcraft.
H(*)M WALL PLATE RECEPTACLE
Wall plate with two, B3M
or B4M male receptacles
mounted (in “D”-shaped
holes to prevent turning)
on standard single
electrical outlet box. Cover
mounting screws included.
? Special order only. Contact Switchcraft.
K(*)F WALL PLATE RECEPTACLE
Wall plate with two, D3F or
D4F female receptacles.
Mounts on standard single
electrical outlet box. Cover
mounting screws included.
Part
Insert
Part
Insert
Number
? H3MS
? H4MS
Finish
Stainless
Steel
Pins
3
4
Number
K3FS
? K4FS
Finish
Stainless
Steel
Pins
3
4
? Special order only. Contact Switchcraft.
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
? Special order only. Contact Switchcraft.
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
